• Support both HID and SPP connection.
• Provide 1D (CYCLOPS-I) and 2D (CYCLOPS-II) barcode reading solutions.
• 3.7V, 720mAH Li-Ion battery pack supports long working hours.
• Perfect wireless barcode data capture device for mobile operations ( Smart phone, iPad, Tablet, and Desktop PC’s ).
• 2MB Flash ROM for data storage in batch mode.
• USB 2.0 Client Compatible.
• Ultra compact size and ergonomics design minimizing operation fatigue.
• Built-in RTC giving time-stamp on each scanned data.
• IP 54 high-level industrial protection maximizing application reliability.

Cyclops II Specifications

Performance

Receiving Device : Linear CCD imager
Sensor Resolution : CCD sensor, 1500 pixels
Light Source : Visible LED 625nm
Optical Resolution : 5mil
Scan Rate : 100 scans/second
Printing Contrast : 20% Minimum
Ambient Light : 110,000 Lux
Reading Distance : 38mm~610mm
Memory : 2MB Flash ROM
                  10,000 min scan data storage

Corresponding code : UPC, EAN, Code128, Code39, Code93, Code 11,ITF (Inter I eaved 2 of 5), Discrete 2 of 5, Chinese 2 of 5,Matrix 2 of 5, Codebar (NW7), MSI,GS1DataBar Omnidirectional,GS1DataBar Limited, GS1DataBar Expended

Key : Scan key/Function key/Reset key

Physical
Dimension : H13.4 x W38 x L85mm
Weight : 50g

Electrical
Battery Type : Li-ion 720mAh
Duration : 15000 scan

Communicaiton
Bluetooth(range) : Ver. 2.1 + EDE Class 2 (10m)
Profile : SPP & HID
Software supported : windows,iOS(5.0 above), Android(4.0 above)
Host Interface Supported : Mini USB

Environment
Radio disturbance : VCCI B
Drop Test : 2-meter※1 drop, and 1-meter Tumble Drop 100-Cycle
Storage Temperature :-25°C ~ 60°C
Operation Temperature : -10°C ~ 50°C
Humidity : 5% ~ 95%
Industrial Protection : IP54
EMC Regulatory : BSMI/NCC/CE/FCC

Cradle : n/a

Accessory : USB cable, Hand strap, User Guide

Warranty : 3 years

※1 Free drop on concrete, 3 times per 6 surface at room temperature
